How to Setup Linksys RE4000W Extender

Linksys RE4000W extender consists of 2 Fast Ethernet RJ45 Ports, which can be used for two wired devices. These dual bands consist of 2.4 and 5 GHz bands that help in maximizing speed by eliminating all traffic. This router is compatible with any router, including the service provider's routers.

To set up Linksys RE4000W Extender, you are required an active 2.4 and 5 GHz wireless network connection, a dual-band router, a wireless network name(SSID), and a protected password, and for improved performance, you need to use security levels such as WPA Personal, WPA2 Personal. Now, the Linksys RE4000W Extender is ready to set up.

Features of Linksys RE4000W Extender

• One of the best feature is that it works with all other router or gateway including routers supplied by any service provider.
• Each extender comes with 2 fast Ethernet RJ45 ports that can be used for two wired devices together.
• The simultaneous dual band feature consisting 2.4 and 5 GHz bands help in reducing traffic and maximizing speed. You can transfer the data upto 300Mbps on each of the band.
• The setup Linksys RE4000W extender is quite easy using the installation wizard as it provides easy installation steps and directs optimal placement.
• This Linksys RE4000W Extender supports with every PC or Mac.

How RE4000W Linksys Extender Eliminates Dead Spots?

The RE4000W Linksys Extender works by extending the wireless coverage of an area. It does by repeating and redistributing the signal from the router to as far reach of your home. The featured Crossband technology allows wireless bands to receive information over one band and transmit on the other band in order to reduce dropped data packets.

Steps to Setup Linksys RE4000W Extender via IP 192.168.1.1

You can setup Linksys RE4000W extender and extend your Internet access in 3 simple steps:

Step 1: Firstly, you need to connect the power cable.

Step 2: Next, you have to plug in the range extender midway between your router and the area without any wifi connection.

Step 3: As the solid light glows on the range extender cover, you will have to connect to the wifi network “Linksys Extender Setup.”

Step 4: In the next step, you have to launch the installed web browser on your system.

Step 5: Once the browser opens up on your screen, you have to enter extender.linksys.com or 192.168.1.1 in the address bar.

Important Note: Optionally, you can even use extender.linksys.setup in case the IP doesn’t works.

Step 6: It will now ask you for the router Username and Password. You can leave the Username tab as blank and type in “admin” in the password’s tab or field.

Step 7: Out from all the available WiFi networks, you will have to choose your Home WiFi Network.

Step 8: Next, you have to punch in your Router’s WiFi password and click on Next button.

Step 9: Here with this step, you can change your LinksysRE4000w Extenders Network Name.

Step 10: Additionally, you will be required to Create Password for your Extender.

Step 11: At the end, you have to register your product by entering in your email information.

How to Reset the Linksys RE4000W to Factory Default Settings?

Certain times there is a need to reset the device even after you setup Linksys RE4000W extender. In order to reset the Linksys RE4000W to its factory defaults, one must press and hold the Reset button present at the top panel of the device for at least five seconds.  Additionally, you may even perform factory reset through the web-based setup page of the router device.

What to Do When you Encounter Errors During Setup?

Sometimes, you might encounter an error while setting up your range extender. This is because the setup software will only detect the range extender in its default state. So, to resolve this, you can reset your range extender and then, run the setup software again.

If you find the Contact Customer support screen, you can reset your range extender and then run the Setup Software again.

Quick Tip: You may even download the latest setup software of the range extender from the Linksys RE4000W Downloads and make sure that you are using an updated version.

What are the Required Settings for Setup Linksys RE4000W Extender?

Before you start setup Linksys RE4000W extender, ensure to have these following things:

• An active 2.4 GHz and 5 GHz wireless network connection
• A dual-band router is necessary to make the range extender work
• Wireless network name (SSID)
• Protected password or security key
• For improved connection and performance, it's recommended to use the following security levels:
• Wi-Fi Protected Access (WPA) / WPA2 Mixed Mode
• WPA2 Personal
• WPA Personal

So, setup Linksys RE4000W extender is all complete and you are set to go now.
